PR-276 Duct Pressure Transducer

Specifications

  • Accuracy*: ± 1% FS
  • Overpressure: 10 PSID
  • Supply Voltage: 12 - 40 VDC; 12 - 35 VAC (VDC output units only)
  • Supply Current: VDC Units - 10 mA max.; mA Units- 20 mA max.
  • Load Impedance: 3K ohms maximum at 40 VDC (mA output units)
                                 1K ohms minimum (VDC output units)
  • Enclosure: 18 Ga. C.R. Steel NEMA 4 (IP-65) 6061T aluminum probe
  • Finish: Baked on enamel PMS2GR88B
  • Compensated Temperature Range: 25°F to 150°F (-4°C to 65°C)
  • T.C. Error: ± 0.0125%/°F (.02%/°C)
  • Operating Temp Range: 0°F-175°F (-18°C-80°C)
  • Media Compatibility: Clean dry air or any inert gas
  • Environmental: 10 - 90%RH Non-Condensing
  • Termination: Unpluggable screw terminal block
  • Wire Size: 12 Ga. max.
  • Weight: 1.0 lb. (.45 kg)
  * Includes non-linearity, hysteresis and non-repeatability

Conformance & Testing

RoHS Compliant
EMC Testing:

BS EN 55022:1998, BS EN 55024:1998,
EN 61000-3-3, EN 61000-4-2,
EN 61000-4-3, EN 61000-4-4,
EN 61000-4-5, EN 61000-4-6,
EN 61000-4-11
